Stage 260C

General Specifications

High Frequency Transducer

1 (25mm) Aluminum dome with Acoustic Lens

Low Frequency Transducer

6.5 (165mm) Polycellulose cone woofer

Recommended Amplifier Power (Full Range)

20-100W RMS

Frequency Response

50Hz-25kHz (-6dB on-axis)

Sensitivity (2.83V@1m)

87dB

Nominal Impedance

8ohm

Crossover Frequency

3000Hz

Inputs

Nickel-plated spring-loaded connectors

Grille Dimensions

Grille Dimensions 9.2in (233mm)

Dia

Cutout Dimensions

Cutout Dimensions 8in (203mm)

Dia

Mounting Depth

3.9in (100mm)

Product Weight (Kg)

1.9Kg

Shipping Carton Dimensions

L 11in (280mm) x W 11in (280mm) x H 5.4in (136mm)

Shipping Carton Weight

5.6lbs (2.54Kg)
