JBL Control 29AV-1

General Specifications

Frequency Range (-10 dB)

37 Hz –18 kHz

Frequency Response (± 3 dB)

43 Hz – 15 kHz

100 Hr Power Capacity

300 Watts Continuous Program Power ; 150 Watts Continuous Pink Noise

Maximum SPL @ 1m

Short-Term = 118 dB; Long-Term = 112 dB

Nominal Sensitivity

90 dB, 1W @ 1 m (3.3 ft)

Nominal Coverage Angle

110° H x 85° V, rotatable

Directivity Factor (Q)

6.7, averaged 500 Hz to 16 kHz

Directivity Index (DI)

8.3 dB, averaged 500 Hz to 16 kHz

Nominal Impedance

8 ohms (THRU setting)

Minimum Impedance

6.3 ohms @ 230 Hz 3.3 ohms @ 4.1 kHz

Crossover Type

3rd order High Pass, 2nd order Low Pass with impedance compensation, 2.5 kHz crossover frequency

Transformer Taps

Transformer Taps 8? nominal

70V = 110W, 55W, 28W & 14W ; 100V = 110W, 55W, & 28W ; Thru Position

Low Frequency Transducer

200 mm (8 in) kevlar cone with pure butyl rubber surround, 50 mm (2 in) voicecoil on fiberglass former

High Frequency Transducer

25 mm (1 in) compression driver, pure titanium diaphragm with patented JBL diamond surround

Included Accessories

1 pc MTC-PC2 input panel cover, InvisiBall mounting base, 6 mm x 260 mm InvisiBall Hex wrench

Optional Accessories

MTC-29CM to install speaker down from the ceiling MTC-29UB U-bracket

Dimensions

Dimensions (H x W x D)

520 x 306 x 277 mm (20.5 x 12.0 x 10.9 in)

Net Weight (ea)

12.2 kg (26.8 lbs)

Shipping Weight (ea)

14.0 kg (30.8 lbs)

Design

Enclosure Material

High impact polystyrene

Grille

Thermoset composite coated steel

Overload Protection

Full-range power limiting to protect network and transducers. Serviceable internal fuse to protect during extreme overload conditions.

Environmental

IEC 529 IP-X4 splashproof rating. Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-Std-202F for salt spray.

Termination

Screw-down terminal strip, zinc plated copper base, nickel plated metal screws/washers. Accepts up to 9 mm outside 4 mm inside open lug (#6, #8 or #10 lug), plus bare wire (up to 12 AWG/2.5 mm)

Safety Agency Rating

Transformer is listed per UL1876.
